10KW Single Phase Grid Tie Inverter

Name: 10KW Single Phase Grid Tie Inverter
SKU: BAU-S10000TL
Availability: InStock

$404.00

1-10kw
Single Phase Grid Tie Inverter

SKU: BAU-S10000TL Category: Solar Inverter

MODEL	BAU-S10000TL
INPUT(DC)
MAX. DC POWER	15000W
MAX. DC VOLTAGE(VDC)	550
MIN SYSTEM START	75/100
MPPT VOLTAGE RANGE(VDC)	100~500
MAX. INPUT CURRENT(A)	28A/18A
MAX. SHORT MPPT	40A/25A
NUMBER OF MPP TRACKERS	2
STRINGS PER MPP TRACKER	2/1
OUTPUT (AC)
NOMINAL OUTPUT POWER	10000W
MAX. OUTPUT POWER	10500W
NOMINAL OUTPUT VOLTAGE/RANGE (V)	208,220,230,240/140~310
AC CONNECTION WITH PE	Single Phase
MAX OUTPUT CURRENT(A)	16
CURRENT DISTORTION(THDI)	＜1.5%
EFFICIENCY
MAXIMUM CONVERSION EFFICIENCY	97.5%
EUROPEAN EFFICIENCY	97.2%
MPPT EFFICIENCY	99.9%
SAFETY AND PROTECTION
DC REVERSE-POLARITY PROTECTION	yes
OVERVOLTAGE PROTECTION	yes
SHORT CIRCUIT PROTECTION	yes
LEAKAGE CURRENT PROTECTION	yes
GRID MONITORING	yes
DC/AC SIDE SPD	yes
GENERAL PARAMETERS
DIMENSIONS	434/340/115mm
WEIGHT	7kg
EMBEDDED DC SWITCH	Optional
NIGHT POWER CONSUMPTION (W)	＜0.2
ISOLATION TYPE	Transformerless
PROTECTION DEGREE	IP65
OPERATING TEMPERATURE RANGE	-25℃~+ 60℃
COOLING CONCEPT	Smart Cooling
ACOUSTIC NOISE LEVEL (DB)	＜25
DISPLAY	Graphic LCD
COMMUNICATION INTERFACE	WIFI; RS485 (optional)
WARRANTY	Standard 5 years
