Solis S5-GR1P10K On-grid Single Phase Inverter

Name: Solis S5-GR1P10K On-grid Single Phase Inverter
SKU: S5-GR1P10K
Availability: InStock

$1,207.00

Brand Name:Solis

Model: S5-GR1P10K

Type: Single-phase

SKU: S5-GR1P10K Category: Solar Inverter Tag: 10kw on-grid inverter

Solis S5-GR1P10K On-grid Single-Phase Inverter

MODEL	S5-GR1P10K
MAX. DC POWER	15kW
MAX. DC VOLTAGE(VDC)	600V
START VOLTAGE	120V
NOMINAL VOLTAGE	330V
MPP VOLTAGE RANGE	100 – 500 V
NO. OF MPP TRACKERS	3 / 3
MAX INPUT CURRENT	14 A / 14 A / 14 A
MAX. SHORT-CIRCUIT CURRENT	22 A / 22 A / 22 A
RATED OUTPUT POWER	10 kW
MAX. APPARENT OUTPUT POWER	10 kVA
MAX. OUTPUT POWER	10kW
RATED GRID VOLTAGE	1/N/PE, 220 V/230 V
RATED GRID FREQUENCY	50 Hz/60 Hz
RATED GRID OUTPUT CURRENT	45.5 A / 43.5 A
MAX. OUTPUT CURRENT	45.9 A
POWER FACTOR	> 0.99 (0.8 leading – 0.8 lagging)
THDI	< 3%.
MAX.EFFICIENCY	98.0%
EUROPEAN EFFICIENCY	97.1%
DC REVERSE POLARITY PROTECTION	yes
SHORT CIRCUIT PROTECTION	yes
OUTPUT OVER CURRENT PROTECTION	yes
SURGE PROTECTION	yes
GRID MONITORING	yes
ANTI-ISLANDING PROTECTION	yes
TEMPERATURE PROTECTION	yes
MULTI PEAK SCAN	yes
INTEGRATED AFCI I 2.0	Optional
INTEGRATED DC SWITCH	yes.
DIMENSIONS (W × H × D)	333 × 579 × 253 mm
WEIGHT	18.5 kg
TOPOLOGY	Transformerless
SELF-CONSUMPTION (NIGHT)	< 1 W
OPERATING AMBIENT TEMPERATURE RANGE	-25 ~ +60°C
RELATIVE HUMIDITY	0 – 100%
INGRESS PROTECTION	IP66.
NOISE EMISSION (TYPICAL)	< 30 dB(A)
COOLING CONCEPT	Natural cooling with internal fan
MAX. OPERATION ALTITUDE	4000 m
SAFETY / EMC STANDARD	IEC/EN 62109-1/-2 and IEC/EN 61000-6-2/-3.
DC CONNECTION	MC4 connector
AC CONNECTION	OT Terminal
DISPLAY	LCD
COMMUNICATION	RS485, Optional: Wi-Fi, GPRS
